Anti-Drone Inconspicuous Obstacle Fence Security Barrier Tank Barrier Wire Mesh
1.Description
Inconspicuous wire obstacle are intended to impede movement, hinder the advance and maneuver of violators of the state border, provide border units and reserves with favorable conditions for blocking and detaining them, limit the action of animals and people on signaling and control means. Inconspicuous obstacle Wire woven into rings into a garland. When opened, it forms a ground covering of wire garlands, which prevents people from entering the closed facility
2.Detailed information
The wire ring connection will form a four-layer space grid with a height of 1.4 meters, a length of 10 meters and a width of 10 meters. The kit consists of 40 connecting rings with a diameter of 0.8 mm annealing wire manufactured as standard GOST 3282-74 and 40 metal posts (25 cm long). The folding size is 1.2 x 0.6K 0.12m.
| Product name | Anti-Tank Barrier Netting |
| Size | 10*10*1.3 M |
| Brand name | Hebei KN |
| Weight | 24KG each pc |
| Material | Annealed steel wire |
3.Production process
Secure the start of the 0.9 mm wire to one of the tubes at the start of a row.Lay a row of ramps in the correct direction, then return in the opposite direction following the pattern of laying the ramps to close the row of ramps.
4.Installation
Secure the start of the 0.9 mm wire to one of the tubes at the start of a row.Lay a row of ramps in the correct direction, then return in the opposite direction following the pattern of laying the ramps to close the row of ramps. Rewind the start of the wire secured to the tube (secured by winding) onto the last turn of the closed ramp. Do not cut the wire at the end of the row! Each row is braided with a single wire along all 20 layers!
1.Stretch two rows of coils to their full length
2.Lay out each row outward
3.Two rows should make four
4.To fix the coil with nails, you need to fix it with a thick coil with nails
5.Hold on to the propeller and move the wire sufficiently as shown in the picture.
6.By this move and stretch the bottom it will shows thick lines, thin lines will extend upward,after fix the outermost layer of coils.
How to install? Attention!
It is impossible to put it back together after unraveling, so it is important to perform all the steps correctly, from the beginning it can be installed on the ground, on the roof, on the fence, and requires 4 to 8 people. The thickest diameter wire should be at the bottom, the tangle fixed to the ground with staples every 1-2 meters, and the wrapped rings above it connected with hooks to raise the wire mesh upward and give it the volume it needs.
5. Our company
Hebei KN Wire Mesh Co,Ltd, was establishedin 2013 is a professional manufacturer engagedin the research, development, production, saleand service of Wire Mesh Container. We arelocated in Anping county hengshui city withconvenient transportation access. Dedicated tostrict quality control and thoughtful customerservice, our experienced staff members arealways available to discuss your requirementsand ensure full customer satisfaction. Ourproducts are also exported to clients in suchcountries and regions as Britain France,Germany, USA, UK Kenya, Zambia,PhilippinesThailand,Korea, New Guinea,Greece, Mexico.We also welcome OEM and ODM orders. Ourcompany always insist on the quality strives forthe survival, to the credibility of development theobjective, wholeheartedly for the domestic andforeign customers, with quality products andfirst- class service and foreign customers, withquality products and first-class service.
